GWN 4×4:4 802.11 ac Wave-2 Weatherproof Long-Range Access Point (GWN7630LR)
The GWN7630LR is a long-range 802.11ac Wave-2 4×4:4 access point designed to provide next generation network coverage for indoor and outdoor environments.
Description
GWN7630LR
key features :
- 2.33Gbps wireless throughput and 2x Gigabit wireline ports
- Dual-band 4×4:4 MIMO technology
- Self power adaptation upon auto detection of PoE/PoE+
- Support up to 250+ concurrent Wi-Fi client devices
- Up to 300-meter coverage range
- Advanced QoS to ensure real-time performance of low-latency applications
- Anti-hacking secure boot and critical data/control lockdown
- Flexibility of detachable/ changeable antenna for different application scenarios
- Embedded controller can manage up to 50 local GWN series APs; GDMS Networking offers unlimited AP management
| Item | Details |
|---|---|
| Client Devices | 250+ devices |
| Range | Up to 300 meters |
| Network Interfaces | 2 × autosensing 10/100/1000 Base-T Ethernet ports |
| PoE Support | PoE / PoE+ (IEEE 802.3af / 802.3at) |
| Maximum Power Consumption | 16.5W |
| 2.4GHz Throughput | 600 Mbps (4×4:4 MIMO) |
| 5GHz Throughput | 1733 Mbps (4×4:4 MU-MIMO) |
| Wi-Fi Standards | IEEE 802.11 a/b/g/n/ac (Wave-2) |
| SSIDs | 32 SSIDs total (16 per radio – 2.4GHz & 5GHz) |
| Antennas | 4 detachable dual-band omnidirectional antennas |
| Security | WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise, WPA3, secure boot, digital signatures |
| Dimensions | 205.3 × 205.3 × 45.9 mm |
| Mounting Options | Wall mount or pole mount |
